36 pages Operator’s Manual for Husqvarna 132R, 133R, 142R, 143R Brush Cutter
Updated: 07-10-2021
Husqvarna 132R, 133R, 142R, 143R Document Transcription:
Husqvarna 132R, 133R, 142R, 143R English – 3 CONTENTS Contents Note the f ollowing before starting: Please read the oper ator’s manual carefully. KEY TO SYMBOLS Symbols …………………………………………………………….. 2 CONTENTS Contents ……………………………………………………………. 3 Note the following…
3
Husqvarna 132R, 133R, 142R, 143R ´z+R1J¶6r¨ 2006-02-07 ´z+R1J¶6r¨ 1150174-26
…36
Husqvarna 132R, 133R, 142R, 143R English – 15 ASSEMBLY Cable adjustment • Throttle cable should be paralleled to flexible shaft. In case of twisting, they should be restored by parallel. • Throttle cable should be adjusted under the bended flexible shaft. 1 Loosen the lock-nut (C) and adjust the cable adjuster sleeve (D) so the stop on the carburettor throttle cam just contacts …
15
Husqvarna 132R, 133R, 142R, 143R 20 – English WORKING TECHNIQUES General working instructions Basic safety rules 1 Look around you: • To ensure that people, animals or other things cannot affect your control of the machine. • To ensure that people, animals, etc., do not come into contact with the cutting attachment or loose objects that are thrown out by the cutting attachment. •…
20
Husqvarna 132R, 133R, 142R, 143R 1 2 4 3 2,4-2,7 mm .095-.106″ 4,25 m 14′ 4,25 m 14′ B 6″ 15 cm A 6″ 15 cm S35 5
…31
Related Searches:
Optional User Guides and Instructions:
KX-TCM410W, 52, panasonic/kx-tcm410w.pdf
LED-737, 6, marveled/led-737.pdf
P800, 208, sony-ericsson/p800.pdf
C710dn, 48, oki/c710dn.pdf
Ceptor BodySet, 4, kyosho/ceptor-bodyset.pdf
FFU2124D, 7, frigidaire/ffu2124d.pdf
Popular Brush Cutter Manuals:
| # | Brand | Model | Document Type/File | Pages | File Size | Last Checked |
|---|---|---|---|---|---|---|
| 1 | U-Line | 29R | U-Line 29R | 2 | 0.55 Mb | 02/05/2021 |
| 2 | Canon | 4400F – CanoScan – Flatbed Scanner | Canon 4400F – CanoScan – Flatbed Scanner | 73 | 3.05 Mb | 09/04/2021 |
| 3 | Sony | STR-DA3700ES | Sony STR-DA3700ES | 64 | 1.84 Mb | 19/05/2021 |
| 4 | Adaptec | MAN-00005-UG | Adaptec MAN-00005-UG | 237 | 2.93 Mb | 16/04/2021 |
| 5 | Emerson | Comfort-Set 90 | Emerson Comfort-Set 90 | 24 | 0.11 Mb | 06/07/2021 |
| 6 | Miele | G 886 | Miele G 886 | 64 | 29/04/2021 |
More Husqvarna Product Types:
- Lawn Mower
- Other
- Timer
- Kitchen Appliances
- Drill
- Fishing Equipment
- Motorcycle
- Power Supply
- Freezer
- Ventilation Hood
- Microwave Oven
- Automobile
- Racks & Stands
- Accessory
- Inverter
- Battery Pack
- Kitchen Appliance
- Blower
- Saw
- Lawn and Garden Equipment
- Brush Cutter
- Remote Control
- Chainsaw
- Dust Collector
- Lawn Mower Accessories
- Lawn Sweeper
- Paint Sprayer
- Scrubber
- Motorcycle Accessories
- Engine
- Power Pack
- Lawn Mower Accessory
- Spreader
- Tractor
- Utility Vehicle
- Outdoor Cart
- Construction Equipment
- DC Drives
- Grill Accessories
- Garden Machinery Accessories
| 1 | CYBEX | PallaS | CYBEX PallaS | 24 | 07.07.2021 | |
| 2 | Apple | Xsan | Apple Xsan | 25 | 0.19 Mb | 05.08.2021 |
| 3 | Insignia | NS-32D120A13 | Insignia NS-32D120A13 | 63 | 08.08.2021 | |
| 4 | RC4WD | Rock Crawler | RC4WD Rock Crawler | 5 | 14.04.2021 | |
| 5 | Hobart Welding Products | AirForce 250ci | Hobart Welding Products AirForce 250ci | 36 | 1.26 Mb | 27.04.2021 |
| 6 | Tricity Bendix | BK110 | Tricity Bendix BK110 | 12 | 0.71 Mb | 02.07.2021 |
| 7 | Polycom | TM300 | Polycom TM300 | 15 | 22.08.2021 | |
| 8 | Savi | MINI MEL P | Savi MINI MEL P | 10 | 04.09.2021 | |
| 9 | CUMMINS | QC5600 | CUMMINS QC5600 | 94 | 05.06.2021 | |
| 10 | Tilia | Maxi 80 – 200 | Tilia Maxi 80 – 200 | 24 | 06.05.2021 |
Cutting equipment
This section describes how to choose and maintain your cutting equipment in order to:
Reduce the risk of blade thrust.
Obtain maximum cutting performance.
Extend the life of cutting equipment.
IMPORTANT!
Only use cutting attachments with the guards we recommend! See the chapter on Technical data.
Refer to the instructions for the cutting attachment to check the correct way to load the cord and the correct cord diameter.
Keep the teeth of the blade correctly sharpened! Follow our recommendations. Also refer to the instructions on the blade packaging.
WARNING! Using an incorrect cutting
!attachment or an incorrectly sharpened blade increases the risk of kickback.
WARNING! Always stop the engine before
!doing any work on the cutting attachment. This continues to rotate even after the throttle has been released. Ensure that the cutting attachment has stopped completely and disconnect the HT lead from the spark plug before you start to work on it.
Dear Customer,
Congratulations on your choice to buy a Husqvarna product! Husqvarna is based on a tradition that dates back to 1689, when the Swedish King Charles XI ordered the construction of a factory on the banks of the Husqvarna River, for production of muskets.The location was logical, since water power was harnessed from the Huskvarna River to create the water-powered plant. During the more than 300 years of beeing, the Husqvarna factory has produced a lot of different products, from wood stoves to modern kitchen appliances, sewing machines, bicycles, motorcycles etc. In 1956, the first motor driven lawn mowers appeared, followed by chain saws in 1959, and it is within this area Husqvarna is working today.
Today Husqvarna is one of the leading manufacturers in the world of forest and garden products, with quality as our highest priority. The business concept is to develop, manufacture and market motor driven products for forestry and gardening as well as for building and construction industry. Husqvarna′s aim is also to be in the front edge according to ergonomics, usability, security and environmental protection. That is the reason why we have developed many different features to provide our products within these areas.
We are convinced that you will appreciate with great satisfaction the quality and performance of our product for a very long time to come. The purchase of one of our products gives you access to professional help with repairs and service whenever this may be necessary. If the retailer who sells your machine is not one of our authorised dealers, ask for the address of your nearest service workshop.
It is our wish that you will be satisfied with your product and that it will be your companion for a long time. Think of this operator′s manual as a valuable document. By following its′content (using, service, maintenance etc) the life span and the second-hand value of the machine can be extended. If you will sell this machine, make sure that the buyer will get the operator′s manual.
Thank you for using a Husqvarna product.
Symbols
WARNING! Clearing saws, brushcutters and trimmers can be dangerous! Careless or incorrect use can result in serious or fatal injury to the operator or others.
Please read the operator’s manual carefully and make sure you understand the instructions before using the machine.
Always wear:
•A protective helmet where there is a risk of falling objects
•Approved hearing protection
•Approved eye protection
Max. speed of output shaft, rpm
This product is in accordance with applicable EC directives.
Watch out for thrown objects and ricochets.
The operator of the machine must ensure, while working, that no persons or animals come closer than 15 metres.
Machines fitted with saw blades or grass blades can be thrown violently to the side when the blade comes into contact with a fixed object. The blade is capable of amputating an arm or leg. Always keep people and animals at least 15 metres from the machine.
Arrows which show limits for handle positioning.
Always wear approved protective gloves.
Wear sturdy, non-slip boots.
Important
IMPORTANT!
The machine is only designed for trimming grass.
The only accessories you can operate with this engine unit are the cutting attachments we recommend in the chapter on Technical data.
Never use the machine if you are tired, if you have drunk alcohol, or if you are taking medication that could affect your vision, your judgement or your co-ordination.
Wear personal protective equipment. See instructions under the heading Personal protective equipment.
Never use a machine that has been modified in any way from its original specification.
Never use a machine that is faulty. Carry out the checks, maintenance and service instructions described in this manual. Some maintenance and service measures must be carried out by trained and qualified specialists. See instructions under the heading Maintenance.
All covers and guards must be fitted before starting. Ensure that the spark plug cap and ignition lead are undamaged to avoid the risk of electric shock.
The machine operator must ensure that no people or animals come closer than 15 metres while working. When several operators are working in the same area the safety distance should be at least twice the tree height and no less than 15 metres.
WARNING! Running an engine in a confined
!or badly ventilated area can result in death due to asphyxiation or carbon monoxide poisoning. Never allow children to use or be in the vicinity of the machine. As the machine is equipped with a spring-loaded stop switch and can be started by low speed and force on the starter handle, even small children under some circumstances can produce the force necessary to start the machine. This can mean a risk of serious personal injury. Therefore remove the spark plug cap when the machine is not under close supervision.
